单元配置 Components:LF: 8"x1 HF: 34mmx1
频响范围 Frequency Response：62Hz - 20kHz(±3dB)
灵敏度 Sensitivity: LF:96 dB ;
阻抗 Nominal lmpedan:8 Ω ;
额定功率Rated Power: HF:100W LF:150W
最大声压级Max@SPL: 121dB;
覆盖角度Dispersion:50°~100*55 °(H x V)
连接器Connector: SPEAKON Nl4x 2;
箱体材质Material: 15MM PLYWOOD;
外型尺寸Dimensions: L415xW520xH1166mm
重量Net Weight:10KG;
